SIZE
Embedment depth in the concrete (mm)
DRILL HOLE DIAMETER (mm)
WRENCH SIZE(mm)
7.5X45
40
6
10
7.5X60
40 / 55
6
10
7.5X80
40 / 55
6
10
7.5X100
40 / 55
6
10
7.5X120
40 / 55
6
10
10.5X55
50
8
13
10.5X65
50 / 60
8
13
10.5X75
50 / 60
8
13
10.5X90
50 / 60
8
13
10.5X110
50 / 60
8
13
10.5X130
50 / 60
8
13
10.5X150
50 / 60
8
13
12.5X65
60
10
15
12.5X75
60 / 70
10
15
12.5X85
60 / 70 / 85
10
15
12.5X100
60 / 70 / 85
10
15
12.5X120
60 / 70 / 85
10
15
12.5X140
60 / 70 / 85
10
15
12.5X160
60 / 70 / 85
10
15
12.5X200
60 / 70 / 85
10
15
14.2X80
75 / 105
12
16
14.2X90
75 / 105
12
16
14.2X110
75 / 105
12
16
14.2X130
75 / 105
12
16
14.2X150
75 / 105
12
16
16.5X80
75
14
18
16.5X115
75 / 110
14
18
16.5X135
75 / 110
14
18
16.5X160
75 / 110
14
18
